Ubiquiti UK-Ultra Omni-Antenna

Beschreibung

Incredibly compact, indoor/outdoor AP with versatile mounting options and long-range external antenna support.

Technische Daten

Höhe

5,2 cm

Tiefe

16,2 cm

Breite

8,5 cm

Uplink

GbE

Weight

100 g (3.5 oz)

Gewicht

0,180 kg

Mounting

Ceiling, Wall, Pole, Table (With Accessory) (Mounts Included) Desktop Stand (Optional)

Dimensions

137 x 84 x 34 mm (5.4 x 3.3 x 1.3")

Efficiency

84.25+%

Power Cable

Included

AC Connector

IEC-320 C6

Power Method

PoE

Coverage Area

115 m² (1,250 ft²)

Data In / PoE

RJ45 Shielded Socket

Input Current

500mA Max.

Output Ripple

200mV pp

Rated Voltage

100–240V AC at 50/60Hz

Response Time

<1 ns

WiFi Standard

WiFi 5

Certifications

CE, FCC, IC, UL, CCC

Inrush Current

<100A peak at 25°C

Output Voltage

48V DC @ 0.32A

2-pair Powering

Pins 4, 5 (+) and 7, 8 (-)

Hardware: 5 GHz

15 dBi

Line Regulation

≤ 3%

Load Regulation

≤ 5%

Spatial Streams

4

Weatherproofing

IPX6

Hardware: System

(1) Power: White/Blue (4) Mesh Signal: Blue

Hardware: Weight

173 g (6.1 oz)

Surge Protection

Difference and common mode

Hardware: 2.4 GHz

10 dBi

Max. Client Count

200+

Shunt Capacitance

<5 pF data

Enclosure Material

Thermoplastic polyester elastomer, polycarbonate, polybutylene terephthalate, polyoxymethylene

Hardware: Antennas

(1) Internal antenna (2) RP-SMA connectors

Mechanical: Weight

450 g (1 lb)

Peak Pulse Current

36A (10/1000 μs) data

Performance: 5 GHz

2 x 2 (DL MU-MIMO)

Clamping Protection

11V Data, 60V Power

Switching Frequency

65 kHz

Grid overview: WiFi5

WiFi 5

Hardware: Insulation

Max. Resistance: 1G ohm @ 50V

Hardware: Management

Ethernet

Max. Surge Discharge

1500A (8/20 μs) power

Mechanical: Mounting

1~2" on pipe outer diameter Compatible with the UK-Ultra

Performance: 2.4 GHz

2 x 2 (DL MU-MIMO)

Performance: 802.11n

6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Grid overview: Uplink

GbE

Hardware: Wind Loading

33.2 N at 200 km/h (7.5 lbf at 125 mph)

Mechanical: Dimensions

138 x 207 x 43 mm (5.4 x 8.1 x 1.7")

Software: UniFi Network

Version 7.5.187 and later

Hardware: Certifications

CE, FCC, IC, Anatel: 06237-24-08356

Hardware: ESD Protection

Absorbing transient current with response to surge voltage from 100V/s to 1kV/µs

Hardware: Mount Material

Polycarbonate, SGCC steel, plastic

Performance: Max. BSSIDs

8 per Radio

Ambient Operating Humidity

10 to 95% noncondensing

Hardware: Max. Capacitance

1.0 pF @ 1 MHz

Ambient Storage Temperature

-30 to 70°C (-22 to 158° F)

Hardware: Channel Bandwidth

HT 20/40, VHT 20/40/80

Hardware: Discharge Current

10kA+

Mechanical: Weatherproofing

IPX6

Grid overview: Radio/Antenna

Omnidirectional

Hardware: Enclosure Material

UV-stabilized polycarbonate

Ambient Operating Temperature

0 to 40° C (32 to 104° F)

Hardware: Operating Frequency

US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5850 MHz

Hardware: Pole Mount Diameter

1~2" (25–50 mm)

Hardware: Data Line Protection

Up to 2.5 Gbps

Hardware: Networking Interface

(1) GbE RJ45 port

Mechanical: Enclosure Material

UV-stabilized polycarbonate, aluminum

Mechanical: Wind Survivability

75 N at 200 km/h (16.7 lbf at 125 mph)

Performance: 802.11ac (WiFi 5)

6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)

Hardware: DC Spark-Over Voltage

90V @ 100V/s

Grid overview: Max. Client Count

200

Hardware: Max. Power Consumption

8W

Hardware: Supported Voltage Range

44–57V DC

Hardware: Ambient Operating Humidity

5 to 95% noncondensing

Hardware: Ambient Operating Temperature

-40 to 60° C (-40 to 140° F)

Hardware: Max. Impulse Spark-Over Voltage

700V @ 1kV/µs

Hardware: Shock and Vibration Certification

ETSI300-019-1.4 Standard
